SB800V 80T Variable Pump Sole Shoe Heels Making Injection Molding Machine

80T Special Sole Making Machine

Max Injection Weight 80T. Suit For Heels Tips. Waterprool Platforms and Heavier Combined Heels Barspace: 305x305 Open: 265 mm Variable Pump

Automate production, improve productivity, meet your production capacity!

20%-80% energy saving than ordinary injection molding machines

Higher product yield and fewer burrs, reducing your workload

Larger space between tie-bars, suitable for larger molds and multi-cavity needs

Higher repeatability precision improves product quality and mold lifespan.

Adopt advanced ejector structure, larger space, and easy maintenance.

Request a Quote

Description

SB* V Series Variable Pump Special Sole/ Shoe Hell Injection Molding Machine

V Series Variable Pump Plastic Injection Molding Machine Is High Effcient Energy-Saving Device Specially Developed For Shoe Heel Industry.

V Series Products Are Equiped With Ultra-Predse High Pressure Bypass Filtering Device Which Can Greatly Enhance Service Lift Of parts In The Hydraulic System And Hydraulic Oil.

The Sensitive Lubricating Pressure Inspection Device For Pattem Locking Parts CanEffectively PreventThe Occurence Of Oil Shortage. Suitabele For Long Time Uniterrupted Operation Of The Machine.

The Highly Effcient And Reliable Imported Vairable Pump Can Reduce The Energy Consumption Of The Whole Machine More Than 30% Lower Than The Constant Pump And Therefore.. Use's Cost Are Effectively Reduced

Sunbun, Your best high speed high precision injection molding machine.

SK 140T Servo Motor Injection Molding Machine

Injection part

Item/type	Unit	SB800V
Screw type		A	B	C
Screw diameter	mm	33	35	38
Screw diame-ter ratio	L/D	21.8	20.5	18.9
Theoretical injection volume	cm³	124	139	164
Injection volume (PS)	g	124	139	149
Injection pressure	MPa	257	229	194
Injection stroke	mm	218
Maximal Rotational Speed of Screw	r/min	235

Clamping part

Item/type	Unit	SB800V
Clamp Tonnage	KN	800
Toggle stroke	mm	265
Distance between tie bars	mm×mm	305X305
Maximum mould height	mm	320
Minimum mould height	mm	90
Ejection stroke	mm	85
Ejector force forward	KN	38
Amount of die thimble	Pcs	1

Others

Item/type	Unit	SB800V
System pressure	MPa	16
Motor power	KW	40066
Heater power	KW	6.3
Bucket capacity	kg	25
Oil tank capacity	L	180
Boundary dimension(L×W×H)	m	3.7X1.2X1.7
Machine weight	Ton
Side dimension of the molding board		450X450
