SB650V 65T Variable Pump Sole Making Shoe Heels Injection Molding Machine

SB650V 65T Variable Pump Sole  Making Shoe Heels Injection Molding Machine
SB650V 65T Variable Pump Sole  Making Shoe Heels Injection Molding Machine
SB650V 65T Variable Pump Sole  Making Shoe Heels Injection Molding Machine
SB650V 65T Variable Pump Sole  Making Shoe Heels Injection Molding Machine
SB650V 65T Variable Pump Sole  Making Shoe Heels Injection Molding Machine
65T Special Sole Making Machine
Max Injection Weight Reach 120g (ABS) Suit For Hells, Combined Heels And Wedge Heels Barspace: 290x290 Open: 240 mm Variable Pump
Automate production, improve productivity, meet your production capacity!
20%-80% energy saving than ordinary injection molding machines
Higher product yield and fewer burrs, reducing your workload
Larger space between tie-bars, suitable for larger molds and multi-cavity needs
Higher repeatability precision improves product quality and mold lifespan.
Adopt advanced ejector structure, larger space, and easy maintenance.
Request a Quote
Description

 SB* V Series Variable Pump Special Sole/ Shoe Hell Injection Molding Machine



V Series Variable Pump Plastic Injection Molding Machine Is High Effcient Energy-Saving Device Specially Developed For Shoe Heel Industry.


V Series Products Are Equiped With Ultra-Predse High Pressure Bypass Filtering Device Which Can Greatly Enhance Service Lift Of parts In The Hydraulic System And Hydraulic Oil.


The Sensitive Lubricating Pressure Inspection Device For Pattem Locking Parts CanEffectively PreventThe Occurence Of Oil Shortage. Suitabele For Long Time Uniterrupted Operation Of The Machine.


The Highly Effcient And Reliable Imported Vairable Pump Can Reduce The Energy Consumption Of The Whole Machine More Than 30% Lower Than The Constant Pump And Therefore.. Use's Cost Are Effectively Reduced


Sunbun, Your best high speed high precision injection molding machine.

SK 140T Servo Motor Injection Molding Machine
Injection part
Item/type Unit SB650V
Screw type   A B C
Screw diameter mm 25 28 32
Screw diame-ter ratio L/D 24 21.5 18.8
Theoretical injection volume cm³ 68 86 112
Injection volume (PS) g 62 86 112
Injection pressure MPa 265 211 162
Injection stroke mm 218
Maximal Rotational Speed of Screw r/min 266
Clamping part
Item/type Unit SB650V
Clamp Tonnage KN 650
Toggle stroke mm 240
Distance between tie bars mm×mm 290X290
Maximum mould height mm 340
Minimum mould height mm 80
Ejection stroke mm 120
Ejector force forward KN 31
Amount of die thimble Pcs 1
Others
Item/type Unit SB650V
System pressure MPa 16
Motor power KW 5.5/7.5/7.5
Heater power KW 4.45
Bucket capacity kg 25
Oil tank capacity L 150
Boundary dimension(L×W×H) m 3.3X1X1.7
Machine weight Ton 2
Side dimension of the molding board   430X430
